Laboratories
| Sr. No. | Room Number | Laboratory Name | Equipment List | Total Cost |
|---|---|---|---|---|
| 1 | 404 | Transportation Engineering Laboratory | 1. Aggregate Impact test to determine the resistance of aggregate to sudden shock 2. Crushing test on aggregate to measure the resistance of aggregate against crushing under gradually applied compressive load 3. Los Angles Abrasion test to measure the abrasion resistance of aggregate materials 4. Penetration test on bitumen to determine the consistency 5. Specific gravity test on bitumen 6. Softening point test on bitumen 7. Flash and Fire point test on bitumen 8. Ductility test to measure the adhesive properties of bitumen | 4,46,035 Rs. |
| 2 | 9A | Environmental Engineering Lab | 1.To determine pH, alkalinity, chlorides, EC and turbidity. 2. To determine percentage available chlorine in bleaching powder, residual chlorine, chlorine demand and break-point chlorination. 3. To determine optimum dose of alum, total, dissolved, suspended and volatile solids. 4. Determination of fluoride and total iron. 5. Determination of sulphates and nitrates. 6. Determination of SVI, BOD and COD. 7. Determination of DO, total hardness, temporary, permanent, calcium and magnesium hardness. 8. Assessment of SPM. | |
| 3 | 405 | Strength of Material Lab | 1.Introduction to Strength of material laboratory 2. Tensile test on mild steel, aluminum. 3. Compression test on mild steel, aluminum. 4. Compression test on timber, brick. 5. Impact test on mild steel, brass, aluminum and specimens. 6. Hardness test on metals 7. Shear test on mild steel/aluminum (Single and Double shear test). 8.Torsion test on mild steel and solid bars. 9. Flexural test on timber, mild steel beams. | 11,38,553 Rs |
| 4 | 355 | Surveying and Basic Civil Engg Lab | 1. Experiment on chaining, ranging, offsetting 2. Use of prismatic compass in traversing 3. R L determination by rise and fall method and line of collimation method 4. Use of digital planimeter 5. Study of Theodolite 6. Measurement of vertical angle 7. Measurement of horizontal angle by direct method 8. Measurement of horizontal angle by repetition method 9. Measurement of vertical angle 10. Single plane trigonometric leveling | 16,92,017.44 Rs |
| 5 | 351 | Geotechnical lab | 1. Specific gravity determination of coarse and fine grained soil by Pycnometer bottle method. 2. Particle size distribution- Mechanical sieve analysis and IS classification as per IS code. 3. Determination of Atterberg’s consistency limits and their use in soil classification as per IS code. 4. Determination of coefficient of permeability by a) constant head b)variable head method 5. Field density determination: a) Sand replacement b) Core cutter method 6. Standard Proctor compaction test 7. Direct box shear test 8. Unconfined compression test 9. Tri-axial test | 6,68,971.91 Rs |
| 6 | 352 | Concrete Technology Lab | 1. To determine fineness of cement by Sieve analysis 2. To determine the standard consistency of cement using Vicat's apparatus. 3. To determine initial and final setting time of cement. 4. Determination of soundness of cement by Le- Chatelier's apparatus and/or Auto Clave test. 5. To determine compressive strength of cement. 6. Determination of particle size distribution of fine, coarse and all in aggregate by sieve analysis (grading of aggregate). 7. Determination of specific gravity of fine aggregates. 8. Determination of specific gravity and water absorption of coarse aggregates. 9. To determine flakiness and elongation index of coarse aggregates. 10. To determine workability of fresh concrete by using slump cone and/or Vee Bee consistometer. 11. To determine compaction factor for workability of fresh concrete. 12. Nondestructive test on concrete by: Rebound Hammer Test, Ultrasonic Pulse Velocity Test. 13. Tests for compressive strength of concrete cubes for M20 or M30 (ACI 211.1-91, IS 10262-2009 and IS 456 2000 | 14,32,409 Rs. |
| 7 | 420 | Computer Lab | 1. Introduction to computer aided drafting 2. Practice exercises on CAD software by using different commands 3. Drawing of plans of Single storeyed buildings using software 4. Developing sections and elevations for Single storeyed building 5. Exercises on development of working of buildings. 6. Exercises on development of Municipal drawing of buildings. | 30,78,096 Rs. |
| 8 | 422 | Engineering Mechanics | 1. Polygon Law of Forces 2. Lami's theorem 3. Bell Crank Lever 4. Jib Crane Apparatus 5. Support Reaction for Beam 6. Centroid of Irrigular Shaped Bodies 7. To Determined Coefficient of Friction 8. Graphical method to Determine resultant 9. Graphical method to determine Support reaction of Beam 10. Graphical method to determine forces in Truss | 2,45,753 Rs. |
